Powerful Traction and Mobility
Maximized Mileage
| SIZE | PLY | PATTERN DEPTH（mm） | SPEED RATING | LOAD INDEX | OVERALL SIZE | LOAD | STANDARD PRESSURE (kPa) | STANDARD PRESSURE (psi) | ||||
| SECTION WIDTH（mm） | OVERALL DIAMETER （mm） | SINGLE LOAD (KG) | DUAL LOAD (KG) | SINGLE LOAD (LBS) | DUAL LOAD (LBS) | |||||||
| 295/60R22.5 | 18 | 20.5 | K | 150/147 | 292 | 932 | 3350 | 3075 | 7390 | 6785 | 900 | 130 |
| 295/80R22.5 | 18 | 20 | M | 154/149 | 298 | 1050 | 3750 | 3250 | 8270 | 7165 | 850 | 123 |
| 315/60R22.5 | 20 | 20.5 | L | 154/148 | 313 | 956 | 3750 | 3150 | 8270 | 6940 | 900 | 130 |
| 315/70R22.5 | 20 | 18.5 | 154/151M 156/150M | 312 | 1020 | 3750 | 3450 | 8270 | 7610 | 900 | 130 | |
| 315/80R22.5 | 18 | 20.5 | 154/151M 157/154L | 312 | 1082 | 3750 | 3450 | 8270 | 7610 | 830 | 120 | |
| 315/80R22.5 | 20 | L | 157/154 | 312 | 1082 | 4125 | 3750 | 9090 | 8270 | 900 | 130 | |
